AVAILABLE TO ORDER WITH FREE GIFT
SCOTT LUMEN 905 BIKE
cumulus white/carbon black
An eMTB with the weight of an MTB, starting at 15.5kg! Take the best Cross-Country/Trail platform to date, the Spark 900, top it off with 130mm of travel paired with a 140mm fork, add silent and powerful electric assistance, yet keep its legendary lightweight DNA, and you are ready to ride any trail at Nino’s speed.
Model : 423358
FrameCarbon HMXIntegrated Suspension TechnologyFlex Pivot / Adjustable head angleSyncros Cable Integration SystemTQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
TravelFront: 140mm / Rear: 130mm
ForkFOX 34 Float Rhythm Air Grip3-Modes / Kabolt 15x110mm axle / tapered steerer44mm offset / Reb. Adj. / Lockout / 140mm travel
Rear ShockFOX NUDE 6T EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendLow Speed Adj. / Custom large Air volume / Reb. Adj.Bearing Hardware / Travel 130-90-Lockout / T165X45mm
Remote SystemSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
E.Drive SystemTQ HPR50
Drive UnitTQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
BatteryTQ Internal 360Wh
DisplayTQ HPRBluetooth / ANT+ / Dedicated Smartphone app
ChargerTQ 100-240V-4A
Rear DerailleurSRAM S1000 Eagle AXS Transmission 12 SpeedWireless Electronic Shift System
ShiftersSRAM AXS Pod Controller
CranksetFSA Alloy
Chainguidee*thirteen / e*spec Slider
ChainringSCOTT custom spider / SRAM Eagle Transmission 34T chainring
ChainSRAM CN GX Eagle Transmission
CassetteSRAM Eagle XS 1270 Transmission 10-52
BrakesShimano Deore M6120 4 Piston Disc
RotorFront: SM-RT64 CL 180mm / Rear: RT-EM600 CL 180mm
HandlebarSyncros Fraser 2.0 DC Alloy 6061 D.B.mini Rise / back sweep 8° / 760mmSyncros Performance XC lock-on grips
H'stemSyncros DC 2.0Syncros Cable Integration System0° rise / 6061 Alloy / 31.8mm / 1 1/8"
SeatpostSyncros Duncan Dropper Post 2.031.6mm / S & M size 125mm / L size 150mm / XL size 170mm
SeatSyncros Tofino 2.0 RegularCRMO rails
HeadsetSyncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)Formula CL-811 / 15x110mm
Hub (Rear)Formula CL-148S / 12x148mm
SpokesStainless Black 15G / 1.8mm
RimsSyncros X-30S / 32H / 30mmTubeless ready
Front TireSchwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Soft
Rear TireSchwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Grip
ExtrasSRAM AXS Extension Cord
Approx weight in KG17.9
Approx weight in LBS39.46
Max. System Weight128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
